Dongfeng 3.2 Ton Lorry Mounted Crane With Manipulator 1898-3329 Mm Span

Product Categories

Henan Liyue Machinery Equipment Co., Ltd.

Contact Now

Name: Dongfeng 32 Ton Lorry Mounted Crane With Manipulator 18983329 Mm Span
Brand: LIYUE
Price: 7 USD

Place of Origin : Henan, China

Brand Name : LIYUE

Packaging Details : Nude packing

Supply Ability : 3000 Unit/Units per Year

Price : $7,000.00/units 1-4 units

Feature : TRUCK CRANE

Showroom Location : Indonesia

Condition : New

Application : Construction

Rated Loading Capacity : 3 Ton

Rated Lifting Moment : 6.8 T.M

Max. Lifting Height : 9 m

Span : 1898-3329 mm

Warranty : 1 Year

Hydraulic Cylinder Brand : MOOG

Hydraulic Pump Brand : Changjiang

Hydraulic Valve Brand : Liyuan

Engine Brand : YUNNEI

UNIQUE SELLING POINT : High operating efficiency

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Marketing Type : New Product 2020

Warranty of core components : 1 Year

Core Components : Bearing, Gearbox, Engine

Weight (KG) : 1290 kg

Product name : Truck Mounted Crane

Crane type : Truck Crane Mobile Crane Hydraulic Crane

Hydraulic parts : Famous Brand Hydraulic Parts

Capacity : 1-3 Ton Truck Crane

Boom type : Hydraulic Straight Arm

Color : Customer Requirements

Usage : Construction Lifting

Rotation Angle : 360 Degree

Installation space : 850 mm

High quality : Mobile Crane Lifting Capacity

Contact Now

1898-3329 Mm Span Dongfeng 3.2 Ton Lorry Mounted Crane With Manipulator 1-3 Ton Capacity

Product Description

NOTE: The price is only for crane part.

Project		Unit	Value
Crane Dimension	Crane Model	-	SQ 3.2T
	Max. Lifting Capacity	kg	3200
	Max. Lifting Height	m	9
	Working Radius/ Span	m	0.67-10
	Rotation Angle	º	360 Continious
	Boom Raising Angle Scope	º	0-75
	Boom Sections	Piece	3
	Outrigger Quantity	Piece	2
	Outrigger Span (Fully Extended)	mm	1898-3329
	Crane Weight	kg	1290
	Hydraulic Tank Capacity	L	35
	Max. Flow Rate of Hydraulic Oil System	L/min	25
	Hydraulic System Rated Pressure	Mpa	21
	Installation Space	mm	850
Working Parameter	The Basic Boom Length	m	3.38-11.0
	Max. Lifting Torque	T.m	6.8
	Max. Slewing Speed	r/ min	2.5
